Project Description
Rigid LED Strip
Description
LED rigid strip light with 60 Diodes 5050 or 5730-This LED strip light is in 14.4w/m . It is cuttable every 3 LED chips for 12vdc and every 6 LED chips for 24vdc . Aluminum PCB width is 10mm , regular is 1.2mm thickness copper, it can be done non-waterproof and aluminum profile casing IP65 waterproof . CRI of 80Ra, 85Ra, 90Ra, 95Ra for Option.
Parameter
| LED Qty | 60 leds/m |
| Power | 14.4 w/m |
| PCB Width | 10mm |
| Strip Length | 1m/pcs |
| LED Brightness | 22-24LM/LED |
| PCB Copper Thickness | 1.2mm |
| Input Voltage | 12/24VDC |
| CCT(K) | 2700-2900K/2800-3200K/4000-4500K/5000-5500K/6000-6500K/10000-12000K/R/G/B/Y |
| Luminous Flux (LM/M) | 1320LM |
| IP Rating | IP20 Non waterproof |
| IP65 glue cover with aluminum profile | |
Application
• Business premises lighting
• Cabinet led lighting
• Linear led lighting
• Exhibition led lighting
• Jewelry counter lighting
• Home led lighting
• Office led lighting
• Led retail lighting
• Led kitchen lighting
• Led strip fixtures
• Decoration lamp for outdoor lighting
• ad. signs
